A complete environmental sediment-core record combining water depth, continuous vibracore runs, recovery and compression, sediment stratigraphy, segmented analytical samples, redox and field observations, laboratory results, criteria status, and a continuous core-photo column.
SC-01 Contaminated Harbour Sediment Core documents a 10 ft vibracore collected in Hamilton Harbour, Ontario, beneath 10.6 ft of water. Five continuous 2 ft runs capture the transition from oxidized surficial silt through black organic sediment and impacted clayey silt to blue-grey glacial clay.
The validation report records Passed status, 100% completeness, Good quality, an 85% confidence score, zero warnings, and zero errors.
The core-photo column follows the entire recovered interval from 0 to 10 ft and remains aligned with the graphic log, sediment descriptions, run boundaries, samples, field observations, and analytical results. The two-page layout continues the photograph cleanly at 5 ft.
This makes the log useful for checking colour transitions, organic-rich zones, laminations, mottling, shell fragments, disturbed sections, and sample boundaries without separating the photographs from the interpreted record.
The completed log passed automated validation with 100% completeness, Good quality, and an 85% confidence score. The report contains zero warnings and zero errors, confirming that the run, sample, observation, laboratory, criteria, and depth records are complete and internally consistent for this example.
Download the files individually. The XML template and completed log can be imported into WinLoG Version 6 and customized for harbour, river, lake, estuary, reservoir, dredging, and contaminated-sediment investigations.
Documents sediment stratigraphy, contamination evidence, sample sections, laboratory results, criteria exceedances, and defensible field observations.
Supports sediment characterization, dredged-material assessment, remediation planning, disposal decisions, and pre- and post-dredging documentation.
Provides aligned review of core photographs, recovered intervals, compression, sample boundaries, field parameters, analytical results, and criteria status.
WinLoG templates can be adapted for company standards and site-specific sediment programs. Headers, depth scales, core-run and recovery fields, photo columns, observation categories, analytical-result columns, criteria fields, footers, and validation rules can all be customized.
